Turbine Flow Meter - STM Series

About Turbine Flow Meter - STM Series

Specification

Usage/Application	Industrial
Model	STM Series, STM-25-F
Brand	SMOOTH FLOWMETER
Output	4-20 mA
Material	SS 316
Application Media	Water, Any Liquid
Display	Local, Remote
Operating Temperature (Celsius)	-10 to 350 oC
Flow range(Min-Max)	1 - 4500 LPM
Automation Grade	Automatic
Operating Pressure	19 Bar
Condition	New
Line Size	1/2" to 8"
Connectivity	Ethernet TCP/IP, RS485
Meter Type	Electronics, Portable
Power Supply (mA)	24 VDC
Accuracy (Percentage)	0.5% of the reading
Battery Type	Lithium 3.6 VDC
Enclosure Type	IP 66 and Ex-Proof Optional
End Connection	THREAD AND FLANGE
Flange Standard	ANSI, DIN

Turbine Flowmeters are mechanical instruments used for measuring the flow rate of liquids and gases. They operate based on the principle of fluid flowing through a turbine rotor, causing it to rotate. The rotational speed of the rotor is proportional to the flow rate, allowing for accurate flow measurement. Turbine Flowmeters are commonly used in various industries for their versatility, wide flow range capabilities, and compatibility with different fluids.

Key Features:

• Wide Flow Range: Turbine Flowmeters offer a wide range of flow measurement capabilities, from low to high flow rates. They can accurately measure both small and large volumes of fluids, making them suitable for applications with varying flow requirements.
• Versatility: Turbine Flowmeters can be used for measuring the flow of various liquids and gases, including water, fuel, oil, chemicals, natural gas, and compressed air. They are suitable for a wide range of industries, including oil and gas, water treatment, chemical processing, HVAC, and automotive.
• High Accuracy: Turbine Flowmeters provide precise flow rate measurements, typically within +0.5% to+1% of the measured value. This level of accuracy ensures reliable process control, accurate billing, and quality assurance in industrial applications.
• Compact and Lightweight Design: Turbine Flowmeters have a compact and lightweight design, making them easy to install and integrate into existing piping systems. They are suitable for applications where space is limited or portability is required.
• Wide Operating Temperature and Pressure Range: Turbine Flowmeters can operate effectively across a wide range of temperatures and pressures. They can handle high-pressure and high-temperature fluids, making them suitable for demanding industrial environments.
• Low Pressure Drop: The flow path in Turbine Flowmeters is designed to minimize pressure drop, ensuring efficient fluid flow and reducing energy consumption. This feature is particularly important in applications where maintaining system efficiency is crucial.
• Long Service Life: Turbine Flowmeters are known for their durability and long service life. They are constructed with robust materials, such as stainless steel, ensuring resistance to corrosion and wear, even in harsh operating conditions.
• Electrical Output Options: Turbine Flowmeters provide electrical output signals for easy integration with control systems and data acquisition devices. They offer options such as pulse output, analog output, or digital communication protocols, enabling seamless connectivity and data transmission.
• Easy Maintenance: Turbine Flowmeters require minimal maintenance. They do not have any complex components or moving parts, reducing the need for frequent calibration or repairs. Routine maintenance typically involves cleaning and inspection, ensuring uninterrupted flow measurement.
• Local Display and Totalizer: Many Turbine Flowmeters come with a local display that shows real-time flow rate and totalized volume. This feature allows for convenient on-site monitoring and data recording without the need for additional instrumentation.
• Bi-Directional Flow Measurement: Turbine Flowmeters can measure flow rates in both forward and reverse directions. This capability is beneficial in applications where flow reversal can occur, such as in industrial processes or fuel dispensing.
• Explosion-proof Options: Turbine Flowmeters are available in explosion-proof designs, suitable for hazardous environments where flammable gases or liquids are present. These meters comply with safety regulations and standards, ensuring reliable and safe operation.

Additional Information:

• Item Code: STM-25-F
• Pay Mode Terms: T/T (Bank Transfer)
• Port of Dispatch: Mumbai
• Production Capacity: 200 Meter
• Delivery Time: Ex-Stock
• Packaging Details: Carton Box.

Technical Details

Superior Construction & Longevity

Built from premium SS 316 stainless steel, the STM Series Turbine Flow Meter ensures exceptional strength and protection against corrosive industrial fluids. Its resilient design makes it suitable for demanding industrial environments and ensures long service life, reducing maintenance costs and downtime.


High Accuracy & Broad Measurement Range

This flow meter achieves an impressive accuracy of 0.5%, making it a dependable choice for applications requiring precise monitoring. The wide measurement range, from 1 to 4500 LPM, allows users to deploy the meter across various processesdelivering reliable readings for both low and high flow rates.


Flexible Installation & Easy Power Supply

The STM Series operates on a standard 24 VDC power supply, resulting in easy integration with industrial control systems. Its compact design and versatile mounting options streamline the installation process, making it an ideal solution for both new projects and retrofits.
